Mirador Recessed
Non-maintained LED Emergency Light
The Mirador Recessed is an ultra-bright wide angle recessed mounted emergency light that provides emergency illumination to allow the occupants of the building to safely exit in the event of mains power failure.
It is a non-maintained emergency light that achieves a high emergency classification of D80 as per AS/NZS 2293. It uses an environmentally friendly LiFePO4 battery with a long lifespan and a fast-charge rate.
It is well suited for use in offices, commercial, retail, education, strata, residential & health care buildings.
Product Downloads
Secure Zone Documents
Log in to access our secure documents area, where you'll find the latest IES files, spacing guides, installation instructions, and answers to frequently asked questions for all our lighting products.
If you do not have a login you can request access.
Product Features
Key Features
Operating Mode - Non-Maintained
Double disc design to cover 70-150mm cutout
Emergency Classification D80
Compliant to AS/NZS 2293
IP20 - Ingress protection
Commissioning Self-Test: Automatic commissioning test 16 hours after install
Duration Self-Test: Automatic duration testing every 3 months
Long life LiFePO4 battery
5 year warranty (2 years for battery)
Applications
MODEL | DIMENSIONS (mm) | RATED POWER (W) | WEIGHT (kg) |
MIRA EL - D80 | 230 x 160 x 65 | 4 | 0.6 |
OPTICAL |
|
Light source | Osram LEDs |
Mode of operation | Non-Maintained |
Emergency Duration | >180 minutes |
ELECTRICAL |
|
Power consumption (W) | 7W Charging Mode 4W Standby Mode |
Operating voltage & frequency | 220-240VAC, 50Hz |
Charger | BMS controlled constant voltage charging |
Battery type | LiFePO4 |
Battery rating | 3.2Ah, 3.2V, 10.24Wh |
Protection | Overcharge, low voltage disconnect, overcurrent, short circuit |
Fitting Type | Class II Electrical |
ENVIRONMENTAL |
|
IP rating | IP20 |
Weight | 0.6kg |
Ambient temp. range | 1°C to +40°C |
Material Composition (body) | Flame retardant ABS |
Relative Humidity | 0 to 90% |
CONTROLS |
|
Testing facility | Manual test switch |
Indicators | Battery charger green LED |
COMPLIANCE |
|
AS/NZS 2293 | D80 |
