Chamaeleon Deco 3

Microwave sensor controlled bulkhead light

Product enquiry

Overview

A robust bulkhead light that is easy to customise, adjustable brightness and dual colour temperature switch.

Ideal for every corridor, lobby and building exterior. It is available in emergency and nonemergency.

Product Downloads

Click the below links to download guides, datasheets and more.

Secure Zone Documents

Login to view the latest IES files, spacing guides, installation guides and frequently asked questions.

Login
5 Year Warranty 1 Emergency (1) Daylight Sensor 1 Microwave Sensor 1 IP66 Rating IK10 Rating 1 Core Range (1)
Highlights

Key Features

  • Emergency & non-emergency options available
  • Adjustable brightness - 100%/70%/50% luminance options within same fitting
  • Dual colour switch - with the flick of a switch choose either 3000K warm white or 4000K natural white colour tone
  • 2 & 3 Step sensor dimming - offers full, standby & off modes
  • Smart daylight sensor - your lights only turn on when needed
  • Flicker free
  • Low standby power - 0.5W to 5.5W
  • Expected life >54,000 @L70 delivered by high quality LEDs
  • 5 year warranty

Applications

Corridors Fire stairs Foyers Lobbies Toilets
Technical Info
 PRODUCT RANGE
  D3-CHAM  Chamaeleon Deco 3 Standard with built-in microwave motion & daylight sensor
  D3-CHAM-E  Chamaeleon Deco 3 Emergency with built-in microwave motion & daylight sensor
  D3-CHAM-P  Chamaeleon Deco 3 Standard
  D3-CHAM-E-P  Chamaeleon Deco 3 Emergency
  D3-CHAM-HO  Chamaeleon Deco 3 High Output With built-in microwave motion & daylight sensor
  OPTICAL
  Light source                       LEDs
  Lumen output     700lm - 2250lm
  CRI     Ra>80
  CCT     Ra>3000K or 4000K (colour selectable)
  ELECTRICAL
  Power consumption     16W Standard, 17W Emergency, 23 High Output
  Standby light level     25%, 10% & off
  Standby power     0.5W - 5.5W
  Operating voltage      220 -240 V AC, 50/60Hz
  EMERGENCY LIGHT
  Battery type     6.4V 1500mAh LiFePO4
  Discharge time    90 minutes
  ENVIRONMENTAL
  IP rating     IP66
  Impact rating     IK10
  Weight    2.5kg standard, 2.9kg emergency
  Temperature range    -20°C to +40°C (Standard), 0°C to +40°C (Emergency)
  Material Composition (Body)    Die Cast Aluminium
  Material Composition (Diffuser)    Polycarbonate
  Expected Lifespan    >54,000 hours @L70
  CONTROLS
  Selectable Brightness                                                                                         Allows for adjustable brightness, select 1500lm, 1000lm or 700lm
  Smart daylight sensor     Standby at dusk, full light when motion is detected and switches off automatically with morning light
  Integrated motion sensor     2 & 3-step dimming to standby level or off
  Spare Parts
  Replacement battery pack                                 6.4V 1500mAh LiFEPO4 Part # SPC-BATT-D3
